Input data
| AC operation | |
| Nominal input voltage range | 100 V AC ... 240 V AC |
| Input voltage range | 85 V AC ... 264 V AC |
| 95 V DC ... 250 V DC | |
| Input voltage range AC | 85 V AC ... 264 V AC |
| Input voltage range DC | 95 V DC ... 250 V DC |
| Voltage type of supply voltage | AC/DC |
| Inrush current | < 15 A (typical) |
| Inrush current integral (I2t) | < 0.6 A2s |
| AC frequency range | 45 Hz ... 65 Hz |
| Frequency range DC | 0 Hz |
| Mains buffering time | typ. 26 ms (120 V AC) |
| typ. 160 ms (230 V AC) | |
| Current consumption | 0.6 A (120 V AC) |
| 0.3 A (230 V AC) | |
| Nominal power consumption | 71.7 VA |
| Protective circuit | Transient surge protection; Varistor |
| Power factor (cos phi) | 0.59 |
| Typical response time | < 0.5 s |
| Input fuse | 3.15 A (slow-blow, internal) |
| Recommended breaker for input protection | 6 A ... 16 A (Characteristics B, C, D, K) |
| Efficiency | > 85 % (for 230 V AC and nominal values) |
| Output characteristic | U/I |
| Nominal output voltage | 12 V DC ±1 % |
| Setting range of the output voltage (USet) | 10 V DC ... 16.5 V DC (> 12 V DC, constant capacity restricted) |
| Output current Imax | 4.9 A |
| Nominal output current (IN) | 3 A (-25 °C ... 55 °C) |
| 3.3 A (-25 °C ... 40 °C permanent) | |
| Derating | 55 °C ... 70 °C (2.5%/K) |
| Feedback voltage resistance | ≤ 25 V DC |
| Protection against overvoltage at the output (OVP) | < 25 V DC |
| Control deviation | < 1 % (change in load, static 10 % ... 90 %) |
| < 2 % (change in load, dynamic 10 % ... 90 %) | |
| < 0.1 % (change in input voltage ±10 %) | |
| Residual ripple | < 40 mVPP (20 MHz) |
| Output power | 36 W |
| Peak switching voltages nominal load | < 35 mVPP (20 MHz) |
| Maximum no-load power dissipation | < 0.5 W |
| Power loss nominal load max. | 6.4 W |
| Rise time | < 0.5 s (UOUT (10 % ... 90 %)) |
| Connection in parallel | yes, for redundancy and increased capacity |
| Connection in series | yes |
